Sm@rtLine Data Cockpit
Sm@rtLine Data Cockpit is a unique software middleware which enables the use of sensors and analyzers for the collection, review and approval of trial results. SDC provides flexible and modern interfaces to transfer the device data to higher level systems like MES, ELN, LIMS or Historian systems. Automate your data handling and use SDC as a black-box system or use the SDC web UI to implement approval and review steps.
What is SDC?
Close the gap between LIMS, MES, DCS and the laboratory devices
SDC is a middleware which is placed between the sensors and the analyzers for the BIO-API processes and the interface to ERP (enterprise ressource planning), LIMS (laboratory information system), MES (manufactoring execution system) and DCS (distributed control system) systems. SDC provides standardized, flexible interfaces for these systems which deliver calculated and evaluated data.
Increase your knowledge
The technican is no longer required to manually start and read measurements from the devices, but rather, the measurements for these devices are reported centrally on the SDC server. SDC allows you to measure faster and more frequently and save the evaluated data in a central system. From this data, you can form golden batch and compare your measurement and calibration curves together with multiple analyzers in a graph.
Improve your quality
SDC supports your implementation of PATH / QbD (Process Analytical Technology / Quality by Design). These concepts strive to ensure a predefined product quality by implementing measures to improve understanding of the manufacturing process by using real-time measuring for all attributes. SDC supports these requirements by providing data transparency, reliability and traceability instead of manual measurement, where accuracy of data and precisely timed sampling cannot be guaranteed.
Reduce your costs
SDC incorporates validated interfaces which have been approved by our many satisfied customers. This reduces your costs for validation and integration of the analyzers as well as reducing costs for the validation of the data handling. Overall, your costs are optimized through the improved data quality, your reaction time improves, production is streamlined and yield can be increased.
What can SDC do for you?
Web based
SDC is a web- and database centered server platform that can be used from every client without special installation.
Safe rights management
SDC includes management of user rights which guarantees safe access to data.
Remote control
SDC is capable of controlling analyzers remotely so that the operator is using one consistent GUI when performing his tasks.
Control
The operator can create, start and evaluate the analyzer measurements in a central system. The approved results can be uploaded to a foreign system (e.g. LIMS, MES or ERP).
Calculate
SDC offers the functionality of generating measurement results based on the data retrieved from the analyzers. Available calculation methods include averaging and trypsinization.
Multiple devices
SDC gives you the ability to combine a multitude of analyzers and sensors to form one system and to evaluate and compare the results.
Middleware
SDC is a middleware between LIMS, MES and DCS systems and the laboratory areas "research", "development" and "production".
Centralized data
SDC provides a central master data management of devices, samplings, samples and users.
Compare
SDC gives you the ability to compare measurements from research, development and production (e.g. interface calibration data) comprehensively.
Benefits
General benefits
Reliability of data
SDC shortens measurement times, which leads to more frequent data and therefore to more knowledge about correllations between critical parameters. Reproducable and automated cell culture analysis improves the reliability of data.
Central database
The central database provides a unique point of information. Data-analysis occurs within ONE database and not in many different databases. Efficient data-evaluation occurs in One system for flexible data-analysis and reporting.
Global visibility
Global data collection increases the visibility of different processes. Global task sharing is facilitated.
Data availability
SDC delivers the data simply and transparently. The operator saves valuable time on the preparation of measurements and data transfer.
Transparency and traceability
SDC makes a comprehensive correlation of analyzer and sensor measurements in research, development and production possible and creates transparancy and traceability.
Calibration data
Calibration data during a product lifecycle (research, development and production) can be compared and contrasted regardless of the device used.
User benefits
Sample handling
Measurements can be repeated easily and they can be prepared while the analyzers are still working. It is possible to monitor measurement progress from anywhere within the company‘s network, including status observation of devices and calculation of time remaining. The measuring procedures of the analyzers are controlled without further user action.
Data evaluation / calculation
Individual measurement results of the analyzers and sensors can be evaluated and calculated into a single result (e.g., mean value, trypsinization). Measurement results can be evaluated / calculated according to batch ID and then displayed graphically in a „time cultivation chart“. The integrated batch comparison enables comparison with the golden batch.
Intuitive system
SDC’s modern and intuitive operating concept is grounded in practical experience, resulting in wide acceptance and minimizing need for on-the-job training.
Validation effort
SDC reduces the validation efforts tremendously by replacing the manual transaction and processing of data by the user.
GMP conforming data handling
Paperless data handling of measurements and data transfer to foreign systems (LIMS, MES, ERP) occurs with electronic signatures and change logs in consideration of 21 CFR Part 11. This ensures the data integrity of all measurements and further parameters. The operator can transfer data for special reports or evaluations easily to Excel.
IT benefits
Remote solution
SDC can be used as a remote solution for facilities regardless of location. Due to its integrated web technology, SDC can be used within the complete network centrally or remotely. Due to modern web technology, no additional installation work is necessary at the client site.
Interfaces
SDC has an open interface concept that enables the connection of LIMS, MES and ERP through XML, SQL and OPC.
New analyzers
The adapter concept for the connection of analyzers and sensors allows for a continual expansion of the system.
Administration
User administration (user- and rights-management) can be linked to the active directory.
Backup
SDC supports the central data backup of results and images.
Setup
A setup oriented toward master data enables conformity and expandability.
IT concept
SDC is a fully developed .NET technology with an Ajax GUI framework and MVP architecture.
Production benefits
Real time
Real-time data leads to more accurate process adjustment. Real-time monitoring increases process understanding.
Ready for automation
SDC creates the basis for future automated processes. The development data can be compared to the production data and all process information (sensors and analyzers) can be viewed on a common timeline. The golden batch can be formed through real-time monitoring for „Closing the Loop“ (QbD = Quality by Design).
Boost of quality and yield
More effective and faster processing time of trials makes more frequent measuring possible, optimizes process monitoring and boosts both quality and yield.
Consolidation
With SDC, the user can consolidate all sensors and analyzers used in fermentation research, development and production into a single system. This method makes the work easier and safer.
Supported Instruments
Status | Price-Kat | Manufacturer | Model | Type | Technology |
---|---|---|---|---|---|
Available | B | 908 devices | Rebel | Cell Media Analysis | File |
Available | A | Advanced Instruments | Model 2020 | Osmometer | RS232 |
Available | A | Advanced Instruments | Model 3320 | Osmometer | RS232 |
Available | A | Advanced Instruments | Model A2O | Osmometer | RS232 |
Available | A | Advanced Instruments | Model 3250 | Osmometer | RS232 |
Available | A | Advanced Instruments | Model OsmoPro | Osmometer | TCP |
Available | A | Advanced Instruments | Model OsmoTech | Osmometer | TCP / Web-Interface |
Available | A | Advanced Instruments | Model OsmoTech Pro | Osmometer | TCP (OPC UA) |
Available | B | Advanced Instruments | Model OsmoTech HT | Osmometer | TCP (OPC UA) |
Available | A | Advanced Instruments | Model OsmoTech XT | Osmometer | TCP (OPC UA) |
Available | B | Beckman Coulter | Vi-Cell Blu | Cell Counter | File / TCP (OPC UA) |
Available | B | Beckman Coulter | Vi-Cell XR | Cell Counter | File |
Is no longer supported | Bayer Technology Service | BaychroMAT | Automated Sampling | TCP | |
Available | B | C Technologies Inc. | SoloVPE | Slope Spectroscopy | File / RTF |
Available | B | CAS | CI 153 CLiMET particle counter | Particle counter | |
On Request driver is feasible | Bruker | NIR Spectrometer | Spectrometer | ||
Available | A | ChemoMetec | NucleoCounter NC-202 | Nucleocounter | File |
Available | A | Gonotec | Osmomat 030 RS/D | Osmometer | RS232 |
On Request driver is feasible | Dionex | Dionex HPLC (Chromeleon) | HPLC | ||
On Request driver is feasible | GE Healthcare | ÄKTA | |||
Available | A | Gonotec | Osmomat 3000/3000D | Osmometer | RS232 |
Available | A | Gonotec | Osmomat auto | Osmometer | RS232 |
Available | C | Hach Lange | DR 2800 photo meter | photo meter | USB |
Available | C | Hach Lange | DR 3800 photo meter | photo meter | USB |
On Request driver is feasible | C | Hach Lange | DR 3900 photo meter | photo meter | USB / Ethernet |
Available | A | Hach Lange | TL2350 | Turbidimeter | File (requires development (e.g. Raspberry pi) or Magic Box) |
Available | A | Heidolph | Overhead Stirrer Hei-TORQUE | Stirrer | RS232 |
On Request driver is feasible | Jova Solutions | FermWorks | Bioprocess Control | TCP/MS-SQL | |
On Request driver is feasible | B | Thermo Fisher Scientific | Orion™ VERSA STAR™ Pro | pH/ISE/Conductivity | |
Available | A | Knick | Portavo 907 pH | pH | USB |
On Request driver is feasible | Knick | pH-Meter Calimatic 765 | pH | RS232 | |
Available | E | Mettler Toledo | Compact Titration G20 / G20 S | Titration | LabX |
Available | E | Mettler Toledo | Compact Titration V20 / V30 / C20 / C30 | Titration | LabX |
Available | E | Mettler Toledo | D4 / D5 / D6 / R4 / R5 / RX4 / RX5 | Density/Refractometer | LabX |
On Request driver is feasible | Nova Biomedical | BioProfile 100 | Metabolite | ||
Available | E | Mettler Toledo | DM40 / DM45 / DM50 / RM40 / RM50 | Density/Refractometer | LabX |
Available | E | Mettler Toledo | DX40 / DX45 / DX50 / RX40 / RX50 | Density/Refractometer | LabX |
Available | E | Mettler Toledo | Excellence balances XP / XS / XPE / XSE – LabX | Scale | LabX |
On Request driver is feasible | C | Optocell | CuBiAn HT | Metabolite | RS232 (ASTM) |
On Request driver is feasible | C | Optocell | CuBiAn XC | Metabolite | RS232 (ASTM) |
Available | E | Mettler Toledo | Excellence balances XPR / XSR – LabX | Scale | LabX |
On Request driver is feasible | Pall ForteBio | Octet® RED96 | Bio-Layer Interferometry (BLI) | ||
On Request driver is feasible | Perkin Elmer | Frontier MIR/FIR with ES Spectrometer | Spectrometer | ||
Available | E | Mettler Toledo | MP70 / MP80 / MP90 | Thermal Value | LabX |
Available | E | Mettler Toledo | Quantos automatic dosing systems: XP/XS/XPE | Scale dosing system | LabX |
Available | B | Mettler Toledo | SevenExcellence Instruments (direct) | pH Conductivity | TCP (without Lab-X) |
Available | E | Mettler Toledo | SevenExcellence Instruments | pH Conductivity | LabX |
Available | E | Mettler Toledo | Titration Excellence T5 / T7 / T9 | Titration | LabX |
Available | E | Mettler Toledo | Titration Excellence T50 / T70 / T90 | Titration | LabX |
Available | E | Mettler Toledo | UV7/UV5/UV5Nano/UV5Bio | photo meter | LabX |
Is no longer supported | C | Molecular Devices | SoftMax Pro/Hamilton/SpectraMax | Liquid handling roboter | |
In development | C | Nova Biomedical | BioProfile FLEX | Metabolite Cell count osmometer | TCP (OPC DA) |
Available | C | Nova Biomedical | BioProfile FLEX 2 | Metabolite Cell count osmometer | TCP (OPC UA) |
Available | B | Nova Biomedical | BioProfile phOx | Blood Gas Analyzer | RS232 (ASTM) |
Available | B | Siemens | RAPIDLab 1240 | Blood Gas Analyzer | RS232 |
Available | A | Pall | Palltronic Flowstar IV | Filter Integrity Tester | TCP (OPC UA) / File (XML) |
Available | A | Perkin Elmer | Lambda 25/35 Spectrometer | Spectrometer | File |
Available | B | Radiometer | ABL 805 | Blood Gas Analyzer | RS232 (ASTM) |
Available | C | Rapid Micro Biosystems | Growth Direct | File | |
Available | B | Roche Diagnostics | Cedex Bio | Metabolite | RS232 (ASTM) |
Available | C | Roche Diagnostics | Cedex Bio HT | Metabolite | RS232 |
Available | A | Roche Diagnostics | Cedex Standard | Cell Counter | TCP |
On Request driver is feasible | Thermo Fisher | ICP Raman Spectrometer | Spectrometer | ||
On Request driver is feasible | C | Thermo Fisher | Konelab 60 | Metabolite | RS232 |
Available | A | Roche Diagnostics | cobas b 123 | Blood Gas Analyzer | TCP (ASTM) |
Available | A | Roche Diagnostics | cobas b 221 | Blood Gas Analyzer | TCP (ASTM) |
Available | C | Roche Diagnostics | cobas e 411 | Immunoassays | RS232 (ASTM) |
On Request driver is feasible | C | Waters | Empower | HPLC | .Net |
On Request driver is feasible | WESCOR | Osmometer | Osmometer | ||
On Request driver is feasible | A | WTW | 3310 pH conductivity | pH cond | USB |
On Request driver is feasible | A | WTW | inoLab Multi 9310 IDS | pH cond | USB |
Available | D | Sartorius | ambr 15 | Automated bio reactor sytsem | TCP |
Available | D | Sartorius | ambr 250 | Automated bio reactor sytsem | TCP |
Available | C | Sartorius | Sartocheck 5 Plus | Filter Tester | TCP (OPC UA) |
Available | A | Sartorius | Scales | Scale | RS232 (SBI Protocol) |
On Request driver is feasible | C | YSI Life Sciences | YSI 2700 Select | Metabolite | RS232 |
Available | C | Siemens | Atellica NEPH 630 | Nephelometer | RS232 (ASTM) |
Available | B | Siemens | RAPIDLab 1200 Series | Blood Gas Analyzer | RS232 |
Available | B | Siemens | RAPIDLab 248 | Blood Gas Analyzer | RS232 |
Available | B | Siemens | RAPIDLab 348 | Blood Gas Analyzer | RS232 |
Available | B | Siemens | RAPIDLab 348 EX | Blood Gas Analyzer | RS232 |
Available | B | Siemens | RAPIDPoint 500 | Blood Gas Analyzer | RS232 |
On Request driver is feasible | B | Siemens | Sysmex CS-2500 | ||
Available | D | TECAN | EVO | Liquid handling roboter | File API |
Available | D | TECAN | Fluent | Liquid handling roboter | File |
Available | B | TECAN | Infinite M200 | Plate Reader | File |
Available | B | TECAN | Sunrise | Plate Reader | File |
Available | C | Thermo Fisher | Indiko | Metabolite | TCP |
Available | C | Thermo Fisher | Konelab 20 | Metabolite | RS232 |
Available | C | Thermo Fisher | Konelab 20 XT | Metabolite | RS232 |
Available | A | WTW | 3420 | pH Conductivity | USB |
Available | A | WTW | 3620 | pH Conductivity | USB |
Available | A | WTW | 3630 | pH Conductivity | USB |
Available | A | WTW | inoLab 7310 Cond | Conductivity | USB |
Available | A | WTW | inoLab 7310 Oxi | Oxi | USB |
Available | A | WTW | inoLab 7310 pH | pH | USB |
Available | C | YSI Life Sciences | YSI 2900D | Metabolite | RS232 |
Available | C | YSI Life Sciences | YSI 2950 | Metabolite | RS232 |
In development | C | Thermo Fisher | VisionMate | Highspeed Barcode-Reader | File |
Available | C | Kaiser Optical Systems | Raman Rxn2 | Raman spectroscopy | TCP (OPC UA) |
In development | C | Hunterlab | Vista | Color spectro photometer | TCP |
Available | B | Roche Diagnostics | Cedex HiRes 2.2 | Cell Counter | TCP |
Available | C | Roche Diagnostics | Cedex HiRes 2.3 | Cell Counter | TCP |
Available | C | Roche Diagnostics | Cedex HiRes >= 2.4 | Cell Counter | TCP |
Available | B | Beckman Coulter | Metaflex | ||
Available | A | Knick | Knick Portavo 907 MULTI COND | cond | USB |
Available | F | Werum | PAS-X | MES | MSI |
Available | A | Perkin Elmer | LAMBDA 365 | Spectrometer | File |
Available | B | Thermo Scientific | Genesys 30 | File | |
Available | B | Lighthouse Instruments | FMS-Oxygen Headspace Analyzer FMS-760 | Circular Dichroism-Fluorescence Spectroscopy (CD-FS) | File |
Available | B | Pfeiffer Vacuum | ME2 | Leak/Mass Extraction Tests | File |
Available | A | Hach Lange | TL2360 | Turbidimeter | File (requires development (e.g. Raspberry pi) or Magic Box) |
Available | A | Mettler Toledo | Excellence balances XP / XS / XPE / XSE – RS232/SICS | Scale | RS232 (SICS) |
Available | A | Mettler Toledo | Excellence balances XPR / XSR – RS232/SICS | Scale | RS232 (SICS) |
On Request driver is feasible | Mecmesin | Vortex-dV | |||
On Request driver is feasible | Mettler Toledo | HS153 – Halogen-Feuchtebestimmer HS153 | TCP/IP direct connection | ||
Available | B | Thermo Fisher | NanoDrop One/OneC | Spectral photo meter | File |
On Request driver is feasible | ChemoMetec | Nucleocounter NC-200 | Cell Counter | ||
Available | C | Siemens | BN ProSpec | Nephelometer | RS232 (SerHost/AutoHost) |
On Request driver is feasible | B | Roche Diagnostics | cobas c 311 | ||
Available | C | Siemens | BN II System | Nephelometer | RS232 (SerHost/AutoHost) |
Available | C | Agilent | 1200 Series | HPLC | File |
In development | C | Roche Diagnostics | cobas pure | HL7 | |
On Request driver is feasible | Anton Paar | DMA 4100M | Density and concentration | ||
Available | B | Repligen | SoloVPE | Slope Spectroscopy | Connection with Viper |
Partners
Marketing and Product Partner (worldwide)
Roche GmbH
Sandhofer Str. 116
68305 Mannheim
Tel. +49 621 7590
mannheim.rdd-kommunikation(at)roche(dot)com
www.roche.com
www.custombiotech.roche.com
> click here to watch presentation <
System Partner
(worldwide)
Körber Pharma Software
Lars Hornung
(Sr. Principal - Alliances Technology Partners)
Wulf-Werum Str. 3,
21337 Lüneburg, Germany
Tel.: +49 175 4363675
lars.hornung(at)koerber.com
www.koerber.com
Interface Development Partner (USA)
Advanced Instruments, LLC
2 Technology Way
Norwood, MA 02062
Tel. +1 (781) 320 9000
info(at)aicompanies(dot)com
aicompanies.com
System Partner
(Ireland)
Focus Scientific Solutions
Unit 12 Block 3, City North Business Campus
Stamullen, Co Meath, K32 FA33
Tel. (353)1 8834 964
info(at)focusscientific(dot)ie
focusscientific.ie
System Partner
(USA)
Tetrascience
294 Washington Steet, 11th Floor
Boston, MA 02108
Tel. (857)244-1514
hello(at)tetrascience(dot)com
www.tetrascience.com
System Partner
(USA)
ZONTAL, INC.
1990 West New Haven Avenue | Suite 301
Melbourne, FL 32904
Tel. +1 (801) 949 6827
info(at)zontal(dot)io
www.zontal.io
System Partner
(Switzerland and Europe)
ControlTech Enginering AG
Benzburweg 7
CH - 4410 Liestal
Tel. +41 61 927 9900
Sascha.Zeller(at)cte(dot)ch
www.cte.ch
System Partner
(Singapore and Asia)
ntegrix Solutions Pte Ltd
10 Anson Road #33-04A
International Plaza
079903 Singapore
Tel. +65 9369 8624
bingfai.kwong(at)integrixsolutions(dot)com
www.integrixsolutions.com
System Partner
(Israel and Middle-East)
Gamidor Diagnostics Inc.
Shacham Street 32
Petach Tikva
Tel. +972 03 927 7277
info(at)gamidor(dot)co(dot)il
www.gamidor.co.il
System Partner
(DACH region)
Quindoo - it Solutions GmbH
Hochwachtstraße 24
AT-6330 Kufstein
Tel. +43 5372 208 11 0
christian.nemeth(at)quindoo(dot)at
www.quindoo.at
System Partner
(Germany)
I&L Biosystems GmbH
Königswinterer Str. 409
53639 Königswinter
Tel. +49 2223 9192 0
info(at)il-biosystems(dot)de
www.il-biosystems.com
Marketing and Product Partner
(worldwide)
Genedata GmbH
Landsberger Str. 84
80339 Munich
Tel: +49 89 4581 9010
Fax: +49 89 4581 9015
europe(at)genedata.com
www.genedata.com
Downloads
-
SDC Brochure
Download SDC information brochure in PDF format
-
SDC Touchpanel PC Flyer
Download SDC Touchpanel PC flyer in pdf format.
-
SDC Gateway End User License Agreement
Download the SDC Gateway EULA.
-
SDC Software License
Download the SDC software license.
-
SDC Software Service Contract
Download the SDC software service contract.
-
SDC Lite: Lightweight Data Conversion Tool
Sm@rtLine Data Cockpit Lite (SDC Lite) can import the system export files from Roche Cedex® Bio and Cedex® Bio HT analyzers. The results can be transformed between the system unit and a lab unit. The data can be exported into an excel file with a tab for CAL, QC, Results and Report. The Report page is user defined and can also be saved as a PDF Document.
Contact us for more Information.
News
Genedata and AGU announce their partnership
Click here for the full press release
Körber and AGU announce their partnership
Körber and AGU announce their partnership to further improve the digital transformation of laboratory workflows and MES in the pharmaceutical industry.
Körber, the global leader in Manufacturing Execution Systems (MES) and integrated solutions,
welcomes AGU Planungsgesellschaft für Automatisierungs-, Gebäude- und Umwelttechnik mbH (AGU), a leading provider of middleware integrating a wide range of devices in laboratories,
to its Körber Ecosystem Partner program as a “PAS-X MSI Plug & Produce” partner.
SDC webinar for SDC major version 3
We, the AGU Industrial IT Team would like to thank the participants of our first SDC Webinar.
Our team remains committed to providing high-quality services and support to ensure that you get the most out of our products.
If you wish to recieve the recording of the webinar, please don’t hesitate to reach out to us.
Thank you again for your participation, and we look forward to connecting with you again soon.
SDC Webinar for SDC Major Version 3
We are pleased to announce the new version V3 of our Sm@rtLine Data Cockpit (SDC). SDC has now been available to our life science customers for over 12 years and is now used by the top 25 Pharmaceutical companies in the world.
To let you know what to expect with this major update, we would like to inform you about it in a 1-hour free webinar.
Register here for the webinar on 29th March 2023 at 08:00 AM (CEST) (for Asia and Australia).
https://us06web.zoom.us/webinar/register/WN_ZzTPxOI5RheLqYgA466EHA
Register here for the webinar on 30th March 2023 at 5:00 PM (CEST) (for US and South America).
https://us06web.zoom.us/webinar/register/WN_2bHc-a1bTA-gVh3xeSzRug
You will get the opportunity to ask your questions directly to Klaus Bruch (CEO) and Jörg Lehmann (Product manager)
Register now to make sure you don’t miss it.
After registration, you will receive a confirmation email with information about participation in the webinar.
Tetrascience publishes press release for AGU partnership
TetraScience, the Scientific Data Cloud company, and AGU, a leading provider of middleware that connects to a wide range of sensors and analyzers, today announced a partnership in response to customer demand for accelerated process automation in research to manufacturing.
“We’ve long admired AGU’s reputation in the field of connecting a large variety of devices across laboratories,” said Simon Meffan-Main, Ph.D., VP, Tetra Partner Network. “They are an exemplary partner to the pharmaceutical industry, delivering the highest quality solutions to customers. We’re thrilled to partner so our mutual customers can accelerate scientific and operational outcomes from the instrument level to enterprise IT, creating faster time to value and more robust workflows.”
AGU and Quindoo announce their partnership
AGU and Quindoo – IT solutions GmbH announce their partnership. Quindoo sees itself as an IT validation expert for the pharmaceutical sector (GxP environment) as well as a consultant and software development company. In addition, they are increasingly working with OSIsoft products that are frequently used in the energy and pharmaceutical sectors.
